What do repeated survey visits add to an integrated model?

Source: vignettes/articles/integrated-repeated-visits.Rmd
integrated-repeated-visits.Rmd

Experimental. The model here is fitted through the ordinary gllvmTMB() entry point with the isdm_sources() declaration — the same experimental route as its sibling articles: the interface may change without deprecation, and no released capability claim is made. The example exists so that early users can see what visit structure adds, end to end, on simulated data.

A designed survey earns its keep twice. The two-source article showed the first half: detection/non-detection with known effort anchors the recording levels that presence-only records cannot anchor. This article shows the second half: repeated visits at the same cells, under conditions that vary between visits, let the model tell a poor visit apart from genuinely low ecological intensity. A single zero is ambiguous — the species may not have been there, or the visit may have been short, wet, or badly timed. Replication under varying conditions is what resolves the ambiguity, and it is a property of the survey design, not of any fitting trick.

Everything here stays inside the integrated route’s standing boundary: relative ecological intensity — no abundance, no absolute occurrence probability, and (as the last section makes precise) no free-standing detectability parameter either.

How a visit condition enters the admitted model

Every survey visit in the integrated route is a complementary-log-log thinning of the same shared intensity. For cell cc, species ss and visit vv with known support acva_{cv} and a measured visit condition wcvw_{cv} (observer-hours, weather, time of day):

Ycsv∼Bernoulli(pcsv),pcsv=1−exp⁡[−acvexp(ηcs+wcvδs)], Y_{csv} \sim \mathrm{Bernoulli}(p_{csv}), \qquad p_{csv} = 1 - \exp\!\left[-a_{cv}\, \exp(\eta_{cs} + w_{cv}\,\delta_s)\right],

with ηcs\eta_{cs} the same ecological predictor every source shares. The visit-condition effects δs\delta_s act on the log-intensity scale: a bad visit scales down the effective intensity the visit gets to thin, exactly as a smaller support acva_{cv} would. This is the “abundance-induced detection” view of Royle & Nichols (2003) — detection improves with intensity, and visit conditions shift the rate, not a separate coin-flip.

Two things follow. First, no new interface is needed: wcvw_{cv} is an ordinary covariate column, set to its measured value on survey rows and to zero on portal rows, so trait:cond terms are survey-only by construction — the same source-gating device the two-source article uses for the portal’s bias covariate. Second, this is not the classical occupancy factorisation Pr⁡(Y=1)=p⋅q\Pr(Y=1) = p \cdot q with a separate logit detection process (MacKenzie et al. 2002). That model is deliberately outside the admitted set: a logit detection arm breaks the thinned-Poisson coherence that lets all sources share one intensity, which is why isdm_sources() refuses logit detection declarations at the door. The last section returns to what that boundary costs and buys.

Simulate: a portal stream plus four visits under varying conditions

Six wetland species over 250 cells. The portal stream is the familiar biased count channel. The survey visits each cell four times; each visit has its own condition wcvw_{cv}, simulated independently of the wetland gradient — the same design assumption the GBIF-only article flags for its bias covariate, and it binds here identically.

n_cell  <- 250
n_visit <- 4
cells   <- paste0("cell_", seq_len(n_cell))
species <- c("sedge_wren", "rail", "bittern",
             "sundew", "sphagnum", "darner")

x <- as.numeric(scale(runif(n_cell)))    # wetland gradient (ecology)
b <- as.numeric(scale(runif(n_cell)))    # accessibility (portal bias)
z <- rnorm(n_cell)                       # unmeasured shared gradient

alpha  <- c(-0.4,  0.1, -0.8,  0.3,  0.6, -0.2)
beta   <- c( 0.9,  0.5,  0.7,  1.1,  0.8, -0.3)   # ecology
lambda <- c( 0.8,  0.6,  0.7, -0.5, -0.6,  0.4)
gamma  <- c( 0.6,  0.1,  0.0,  0.4,  0.2,  0.9)   # portal bias
delta  <- c( 0.7, -0.5,  0.3,  0.6, -0.4,  0.5)   # visit conditions

a_g <- 2.0 * exp(0.3 * b)                # portal effort tracks access
a_s <- 0.8                               # per-visit survey support

base <- expand.grid(cell_id = cells, trait = species,
                    stringsAsFactors = FALSE)
ci <- match(base$cell_id, cells)
si <- match(base$trait, species)
eta <- alpha[si] + x[ci] * beta[si] + z[ci] * lambda[si]

portal <- transform(base, isdm_source = "gbif", support = a_g[ci],
  value  = rpois(nrow(base), a_g[ci] * exp(eta + b[ci] * gamma[si])),
  env    = x[ci], access = b[ci], cond = 0, visit = NA_integer_)

visits <- do.call(rbind, lapply(seq_len(n_visit), function(v) {
  w <- rnorm(n_cell)                     # this visit's conditions, per cell
  transform(base, isdm_source = "survey", support = a_s,
    value  = rbinom(nrow(base), 1,
      -expm1(-a_s * exp(eta + w[ci] * delta[si]))),
    env    = x[ci], access = 0, cond = w[ci], visit = v)
}))

dat <- rbind(portal, visits)
dat$trait       <- factor(dat$trait, levels = species)
dat$cell_id     <- factor(dat$cell_id)
dat$log_support <- log(dat$support)
table(dat$isdm_source) / length(species)
#>
#>   gbif survey
#>    250   1000

Note the gating columns: access is the measured accessibility on portal rows and zero on survey rows; cond is the measured visit condition on survey rows and zero on portal rows. Each source keeps its own observation covariates without any new syntax.

One fit, three kinds of coefficient

fit <- gllvmTMB(
  value ~ 0 + trait + trait:env + trait:access + trait:cond +
    offset(log_support) + latent(0 + trait | cell_id, d = 1),
  data   = dat,
  trait  = "trait",
  unit   = "cell_id",
  family = isdm_sources(gbif = poisson(), survey = binomial("cloglog")),
  silent = TRUE
)
fit$opt$convergence
#> [1] 0
health <- check_gllvmTMB(fit)
health[health$component %in% c("optimizer_convergence", "pd_hessian"),
       c("component", "status")]
#>               component status
#> 1 optimizer_convergence   PASS
#> 4            pd_hessian   PASS

Both read PASS on this fit: the optimizer settled, and the curvature at that point is trustworthy (pd_hessian — whether the Hessian is positive-definite; the two-source article walks through what a WARN there means).

The formula now carries three interaction families with three different meanings, and reading them apart is the whole skill of this model class: trait:env is ecology (shared by every source), trait:access is the portal’s recording process, and trait:cond is the survey’s visit process. One fit, and each coefficient belongs to exactly one of the three.

op <- par(mfrow = c(1, 3), mar = c(4, 4, 2, 1))
panel <- function(truth, est, label) {
  lim <- range(c(truth, est)) + c(-0.2, 0.2)
  plot(truth, est, pch = 19, cex = 1.2, asp = 1, xlim = lim, ylim = lim,
       xlab = paste("true", label), ylab = "estimated", main = label)
  abline(0, 1, lty = 2)
  text(truth, est, labels = abbreviate(species, 6),
       pos = rep(c(3, 1), 3), cex = 0.65)
}
panel(beta,  unname(fit$opt$par[grep(":env",    fit$X_fix_names)]), "ecology")
panel(gamma, unname(fit$opt$par[grep(":access", fit$X_fix_names)]), "portal bias")
panel(delta, unname(fit$opt$par[grep(":cond",   fit$X_fix_names)]), "visit conditions")
Three side-by-side scatterplots, each with six labelled species points around a dashed 45-degree identity line on equal axes.

Truth against estimate for the three coefficient families — ecology (shared), portal bias (portal rows only), and visit conditions (survey rows only). One fit on one simulated draw; spread is sampling noise at this design size.

par(op)

All three families recover along the identity line on this draw. The point is not the precision of any single panel — it is that the three processes were separable at all, and that separation came from the design: the visit conditions varied between visits at the same cells, and varied independently of the wetland gradient. The portal-bias panel leans on the same requirement from the other side — access varies independently of env in this simulation, and its recovery depends on that just as it did in the presence-only opener.

Replication is the ingredient, not the visit count

What actually breaks when replication is removed? Refit the same model keeping only each cell’s first visit — same number of survey cells, same condition covariate, no within-cell replication:

dat1 <- rbind(portal, subset(visits, visit == 1L))
dat1$trait       <- factor(dat1$trait, levels = species)
dat1$cell_id     <- factor(dat1$cell_id)
dat1$log_support <- log(dat1$support)

fit1 <- gllvmTMB(
  value ~ 0 + trait + trait:env + trait:access + trait:cond +
    offset(log_support) + latent(0 + trait | cell_id, d = 1),
  data   = dat1,
  trait  = "trait",
  unit   = "cell_id",
  family = isdm_sources(gbif = poisson(), survey = binomial("cloglog")),
  silent = TRUE
)
round(rbind(
  truth        = delta,
  four_visits  = unname(fit$opt$par[grep(":cond",  fit$X_fix_names)]),
  one_visit    = unname(fit1$opt$par[grep(":cond", fit1$X_fix_names)])
), 2)
#>             [,1]  [,2] [,3] [,4]  [,5] [,6]
#> truth       0.70 -0.50 0.30 0.60 -0.40 0.50
#> four_visits 0.64 -0.51 0.17 0.55 -0.39 0.54
#> one_visit   0.60 -0.43 0.22 0.46 -0.28 0.75

With one visit per cell the model still runs — nothing refuses it — but on this draw the visit-condition estimates degrade visibly: each cell now contributes a single Bernoulli draw whose condition effect must be told apart from that cell’s latent ecological state using cross-cell contrast alone. The structural argument says this is no accident: repeated visits at the same cells, with at least one condition that varies by visit rather than only by cell, are what buy the separation, and the visit count matters only through the replication it provides. The comparison above is a one-draw illustration of that argument, not a measured design curve — the design article shows what a measured curve looks like for the cell-count question.

The boundary: detection through intensity, not beside it

The admitted model ties detection to intensity by construction — a species is seen more often where its intensity is higher, and visit conditions scale that rate. What it does not provide is a free-standing detectability parameter per species. If a species is simply hard to see — cryptic colouration, calls that are easy to miss — that shortfall is folded into its recording-level and intercept terms rather than estimated on its own. And its ecological map stays accurate only if the shortfall is roughly constant from cell to cell; if detectability itself varies with habitat, this model cannot separate that from real ecological change.

If your scientific question is about detectability itself — “what fraction of occupied cells does one visit find?” — you want the occupancy factorisation p⋅qp \cdot q with its own detection submodel (MacKenzie et al. 2002; Guillera-Arroita 2017), which is a different estimand and a different likelihood, and is refused at the isdm_sources() door rather than half-supported. If your question is where relative intensity is high and how sources and visits distort your view of it, the route shown here answers it inside one coherent likelihood.

What this route does and does not cover

Covered here: repeated survey visits as additional cloglog rows sharing one intensity; per-visit support offsets; visit-condition effects via an ordinary gated interaction; recovery of ecology, portal-bias, and visit-condition coefficients illustrated on one known-truth draw.

Works but not certified: the estimates themselves — one draw, one design size, nonspatial, balanced visits.

Not available: a separate logit detection process; per-species detectability at fixed intensity; abundance or absolute occupancy from any number of visits; and calibrated confidence intervals for this route.

See also

References

Guillera-Arroita, G. (2017). Modelling of species distributions, range dynamics and communities under imperfect detection: advances, challenges and opportunities. Ecography 40, 281–295. https://doi.org/10.1111/ecog.02445

Isaac, N.J.B., Jarzyna, M.A., Keil, P., et al. (2020). Data integration for large-scale models of species distributions. Trends in Ecology & Evolution 35, 56–67. https://doi.org/10.1016/j.tree.2019.08.006

MacKenzie, D.I., Nichols, J.D., Lachman, G.B., Droege, S., Royle, J.A. and Langtimm, C.A. (2002). Estimating site occupancy rates when detection probabilities are less than one. Ecology 83, 2248–2255.

Miller, D.A.W., Pacifici, K., Sanderlin, J.S. and Reich, B.J. (2019). The recent past and promising future for data integration methods to estimate species’ distributions. Methods in Ecology and Evolution 10, 22–37. https://doi.org/10.1111/2041-210X.13110

Royle, J.A. and Nichols, J.D. (2003). Estimating abundance from repeated presence–absence data or point counts. Ecology 84, 777–790.
